Wio Tracker L1 Pro for MeshCore
Technical Specifications
Verified product data organized in one table
| Product Classification | |
|---|---|
| Product Profile | Tracker / Mesh Device |
| Environment / Deployment | Outdoor |
| Primary Use Cases | Asset, personnel and outdoor tracking |
| Network & Ecosystem | |
| Supported Network / Ecosystem | MeshCore, SenseCAP |
| Connectivity / Protocol | LoRa, MeshCore, Bluetooth, USB, GNSS / GPS |
| Power | |
| Power Method | Battery, Solar, USB-C |
| Solar Support | Yes |
| Physical & Environmental | |
| Certifications | FCC, CE, RoHS ， E U D O C , T E L E C , U K D O C |
| Tracker / Mesh Specifications | |
| GNSS / Positioning | L76K(GPS,BeiDou,GLONASS,QZSS) |
| Tracking / Mesh Modes | MeshCore, GNSS tracking |
| Display | Size: 1.3 inch |
| Detailed Technical Data | |
| Processor | Nordic nRF52840ARM® Cortex®-M4 with FPU runs up to 64 MHz |
| On-chip Memory | 1 MB flash and 256 kB RAM |
| Wireless | LoRa: Based on Wio-SX1262 Wireless Module , supports 862-930MHz |
| GPS | L76K(GPS,BeiDou,GLONASS,QZSS) |
| OLED Display | Size: 1.3 inch |
| Power | Type-C: 5v---1A |
| Certification | FCC, CE, RoHS ， E U D O C , T E L E C , U K D O C |
| Wio Tracker L1 Board with 1.3 inch OLED Display, 3D-Printed Enclosure and battery | x1 |
| LoRa Antenna | x1 |
| HSCODE | 8526919090 |
| USHSCODE | 8526910040 |
| EUHSCODE | 8517180000 |
| COO | CHINA |
Product Overview
Wio Tracker L1 Pro is a MeshCore-based device featuring low power consumption, a built-in rechargeable battery, and a durable enclosure. Designed for field use, it is ready to use out of the box with no assembly required. Wio Tracker L1 Pro for MeshCore comes with pre-flashed MeshCore Bluetooth Companion firmware .
Note: Enjoy 5% off when you purchase any one MeshCore device – the SenseCAP Solar Node P1-Pro (SKU 100023690) or the Wio Tracker L1 Pro (SKU 100030144) . Get up to 8% off when you add both models to your cart. No quantity limits – discount auto-applies at checkout. MeshCore is a multi platform system for enabling secure text based communications utilising LoRa radio hardware. It can be used for Off-Grid Communication, Emergency Response & Disaster Recovery, Outdoor Activities, Tactical Security including law enforcement, private security and also IoT sensor networks. W io T r a c k e r L 1 P r o f o r M e s hC o r e c o m e s w i t h p r e – f l a s h e d M e s hC o r e B l u e t o o t h C o m p an i o n f i r m w a r e . I f y o u w a n t t o b u y L 1 P r o w i t h p r e – f l a s h e d M e s h t a s t i c f i r m w a r e , p l e a s e c lick he re t o b u y . Ready-to-Use Durable Enclosure The L1 Pro comes with a rugged, lightweight enclosure designed for immediate use—no additional assembly required. Whether handheld or clipped onto gear, it’s built for adventure in any environment. Pre-flashed with MeshCore firmware Ready to use out of the box with pre-installed MeshCore B l u e t o o t h C o m p a n io n firmware for seamless setup. Triple Power Supply Options Equipped with a built-in 2000 mAh battery, Type-C fast charging, and solar input support, enabling flexible deployment in diverse environments—perfect for outdoor and mobile use.
