RS485 Carbon Monoxide CO Sensor: Modbus RTU, Air Quality Monitoring, Carbon Monoxide and Temperature
Technical Specifications
Verified product data organized in one table
| Product Classification | |
|---|---|
| Product Profile | IoT Sensor |
| Environment / Deployment | Indoor & Outdoor |
| Primary Use Cases | Asset, personnel and outdoor tracking |
| Network & Ecosystem | |
| Supported Network / Ecosystem | SenseCAP, Private LoRaWAN |
| Connectivity / Protocol | LoRaWAN, Bluetooth, RS485, Modbus RTU, Analog, GPIO |
| LoRaWAN Technical Specifications | |
| RX Sensitivity | 0.028±0.010 uA/ppm |
| Power | |
| Power Method | Battery |
| Input Voltage | 5-28V DC |
| Power Consumption | quiescent current <2mA @12V DC; maximum current during measurement <7mA @12V DC |
| Physical & Environmental | |
| IP Rating | IP50 |
| Operating Temperature | -20 ~ 50 ℃ |
| Operating Humidity | 15 to 90 %RH non-condensing |
| Dimensions | Sensor body: 111 x 25.5 mm (Length x Diameter) |
| Detailed Technical Data | |
| Product Model | S-CO-01A |
| Sensor Description | RS485 Carbon Monoxide CO Sensor |
| Output Interface | RS485, Modbus-RTU |
| Default Serial Communication | Slave address: 1;baud rate: 9600 bps;data bits: 8; stop bits: 1 |
| Power Supply | 5-28V DC |
| Installation | Wall mounting |
| Cable Length | 2 meters |
| Range | 0-2000ppm |
| Resolution | 10ppm |
| Sensitivity | 0.028±0.010 uA/ppm |
| Response Time(T90) | <35 seconds |
| Accuracy | ± 0.3℃ |
| Carbon Monoxide CO Sensor | x1 |
| Mounting Bracket | x1 |
| Plastic Screw | x2 |
| Metal Screw | x2 |
| HSCODE | 9027100090 |
| USHSCODE | 9027894590 |
| EUHSCODE | 9027109000 |
Product Overview
The RS485 Carbon Monoxide (CO) Sensor is a compact, wall-mounted sensor designed for industrial, environmental, smart-home air-quality, and laboratory monitoring. It measures CO concentrations from 0 to 2,000 ppm while also providing calibrated temperature data. In addition, integrated temperature compensation and low baseline drift help maintain stable readings under changing conditions. For easy integration, it supports RS485 Modbus RTU communication and operates on a 5–28 V DC power supply. Moreover, its low-power design, reverse-polarity protection, and built-in surge, TVS, and ESD protection ensure reliable long-term use.
The RS485 Carbon Monoxide CO Sensor is a compact, wall-mounted sensor widely used in industrial processes, environmental monitoring, smart-home air quality systems, and laboratory research. It measures CO concentrations from 0 to 2000 ppm—with a resolution of 10 ppm—and provides calibrated temperature data. Integrated temperature compensation, linear output, and low baseline drift help maintain stable readings under changing conditions. For easy integration, it supports RS485 Modbus RTU communication and low-power 5–28 V DC operation. Moreover, its IP50 design, reverse-polarity protection, and built-in surge, TVS, and ESD protection support reliable long-term use. This sensor is available with an RS485 Modbus RTU interface. It is compatible with the SenseCAP S2100 LoRaWAN® Data Logger , enabling low-power, long-range data transmission over LoRaWAN® networks. Note: This sensor is rated IP50 and is designed for indoor environments. It is not suitable for direct outdoor exposure or locations with water ingress risks. Integrated CO and Temperature Monitoring: Measures carbon monoxide concentrations from 0 to 2000 ppm—with a resolution of 10 ppm—and provides calibrated temperature data. Moreover, its T90 response time of less than 35 seconds enables timely detection of concentration changes. Temperature Compensation and Flexible Calibration :Supports both sensor-sensitivity calibration and standard-gas calibration.
